- Place of Origin: weifangqingzhou
- Brand Name: Shandong Chuanyi water treatment
- Model Number: CY-6000
Description of main process flow of pure water equipment
1, raw water tank (optional)
Storage of raw water for precipitation in water sediment particles and other precipitable material. At the same time buffer of raw water pipe water pressure is not stable in water treatment system caused by the impact. (such as the water pressure is too low or high due to the pressure sensing response).
2 raw water pump
Constant system of water supply pressure, stable water supply.
3 multi medium filter
Using the multiple filter layer of the filter, the main purpose is removal from raw water containing silt, rust, colloid, suspended solids and other particles in 20um above material, using manual valve control or automatic controller for backwashing. Rinse the and so on a series of operation. Ensure the production water quality of equipment, prolong the service life of the equipment. Reverse osmosis equipment
4 activated carbon filter
The system adopts activated carbon filter, activated carbon adsorption of electrolyte ions can not only, but also for ion adsorption. The adsorption still can make Potassium Permanganate oxygen consumption (COD) by 15mg/L (O2) to 2 ~ 7mg/L (O2), in addition, due to the surface by adsorption complex increase concentration, and also play a catalytic role, removal of pigment, odor, a large number of biochemical organic chlorine halide and reduce water value of three pesticide pollutants and remove water (THM) and other pollutants. For backwashing using manual valve control or automatic flushing controller, is a series of operations. To ensure the quality of water production equipment, prolong the service life of the equipment. At the same time, the equipment has a self maintenance system, the operation cost is low since Chen Xia:
5 ion softening system / dosing system
O device in order to take advantage of dissolved solids concentration of emissions and freshwater, in order to prevent the condensed water end, especially RO device in membrane concentrated water side of CaCO3, MgCO3, MgSO4, CaSO4, BaSO4, SrSO4, the concentration of SiSO4 product is greater than the equilibrium solubility constants and crystallization precipitation, damage due characteristics of the original film, before entering reverse osmosis membrane components in, should use ion softener or put the right amount of scale inhibitor to prevent carbonate and precipitation of SiO2 crystals. Pure water equipment
6 precision filter
The precision filter of the suspension in the water residue, and non particles and colloid removal, RO system etc.
Continued equipment operation safer and more reliable. Filter 5um meltblown filter aimed at preventing superior filtering unit, miss more than 5um impurities removed. Prevent into reverse osmosis device damage to the membrane surface, resulting in the damage of membrane desalination performance. Water treatment equipment
7 reverse osmosis system
Reverse osmosis device is with enough pressure to the solution of the solvent (usually water) by reverse osmosis membrane (or semi permeable membrane) and separated, because the process and natural penetration in the opposite direction, therefore it is called reverse osmosis.
Reverse osmosis method can adapt to all kinds of containing salt content in the raw water, especially in high containing salt water treatment engineering, can obtain very good technical and economic benefits. Reverse osmosis desalination rate, high recovery rate, stable operation, covers an area of small, simple operation, reverse osmosis equipment in addition to salt at the same time, most of the bacteria, colloid and high molecular weight organic matter removal.
- Place of Origin: weifangqingzhou
- Brand Name: Shandong Chuanyi water treatment
- Model Number: CY-6000
Processing customization
yes
Model
CY-6000
brand
Kawaichi
Inlet diameter
75 (mm)
Yield of water
6000L/H
Specifications
Single stage
Working pressure
300 (PSI)
